Legrand 880MPFC
Wiremold 880MPFC Omnibox Fire Classified Non-Metallic Floor Box, Concrete/Steel, 50 cu-in Capacity, 1 Gangs, 2 Knockouts, 5-1/2 in L x 4-1/4 in W x 6 in H
Floor Boxes
7329357
880MPFC
Legrand
$0.00
/ ea
- Capacity: 50
- Dimensions: 5-1/2 in L x 4-1/4 in W x 6 in H
- Knockout Size: 1
- Material: Concrete/Steel
- Mounting Type: Concrete/Threaded
- Number of Gangs: 1
- Number of Knockouts: 2
- Series: Omnibox™
- Shape: Rectangle
- Type: Fire Classified Non-Metallic
Wiremold Floor Box, Fire Classified Non-Metallic, Series: Omnibox, 1 Gangs, 2 Knockouts, 1 in Knockout, Rectangle Shape, Concrete/Threaded Mounting, 50 cu-in Capacity, Concrete/Steel, 5-1/2 in L x 4-1/4 in W x 6 in H Dimensions
- Features
- Reducers provided for reduction to 1 in, 3/4 in and 1/2 in conduit
- Minimum concrete depth is 3-1/2 in and maximum concrete depth is 6 in
- Insert spacer should not be removed until after concrete pour
- Cannot gang boxes together and maintain fire classification
- Floor box spacing 2 ft on center, no more than 1 per 65 sq-ft span
- Maximum copper cross section per insert (4) 12 AWG type THHN power conductor or (48) 23 AWG (6 cat 6) tele data conductors
- Box preserves the 2-hours fire rating of the floor in which it has been installed
- Minimum capacity is 50 cu-in and maximum capacity is 100 cu-in
- Surface style activation are available in brass and aluminum versions
- Assembled construction
