Littelfuse LA70QS500-4

Littelfuse POWR-GARD LA70QS500-4 Very Fast Acting High Speed Semiconductor Fuse, 500 A, 700 VAC/VDC, 200/100 kA Interrupt, Cartridge Body
Semiconductor Fuses
6780370 LA70QS500-4
Littelfuse
$0.00 / ea

Littelfuse LA70QS500-4
  • Amperage Rating: 500
  • Body Size: 2 in Dia x 5.09 in L
  • Body Type: Cartridge
  • Indicating/Non-Indicating: Non-Indicating
  • Interrupt Rating: 200/100
  • Mounting Type: Bolt-On/Blade
  • Series: LA70QS
  • Type: Very Fast Acting High Speed
  • Voltage Rating: 700
Littelfuse POWR-GARD Semiconductor Fuse, Very Fast Acting High Speed, Series: LA70QS, Non-Indicating, 500 A, 700 VAC/VDC, 200/100 kA Interrupt, Bolt-On/Blade Mount, Cartridge Body Type, 2 in Dia x 5.09 in L Body Size
QTY
Add to Wishlist
  • Features
  • Very I2T improved protection of equipment
  • Superior cycling ability for long, reliable life on high cycling loading
  • Lower watts loss for cooler operation
  • 700 VAC/VDC rating provides greater design versatility
  • Compact sizes allow downsizing of equipment
  • 200 kA at 700 VAC/100 kA at 700 VDC interrupt rating
