Panduit LCC500-12W-6
Panduit Pan-Lug LCC500-12W-6 LCC-W 2-Hole Compression Lug Connector With Inspection Window, 500 kcmil Stranded Copper Conductor, Die Code: P87, 1/2 in Stud, Tin Plated Copper
Lug Compression Connectors
7164451
LCC500-12W-6
Panduit
$0.00
/ ea
- Barrel Size: 0.84 in ID x 1.06 in OD x 2.5 in L
- Barrel Type: Inspection Window/Long
- Color: Brown
- Conductor size: 500
- Conductor Type: Stranded Copper
- Die Code: P87
- Material: Tin Plated Copper
- Mounting Hole Size: 2-9/16
- Overall Length: 6.12
- Series: LCC-W
- Specifications: 1-3/4 in Stud Hole Spacing, 2-9/16 in L Wire Strip, Tin Plated
- Stud Size: 1/2
- Temperature Rating: 90
- Tongue Size: 1.54 in W x 0.22 in THK
- Tongue Type: Straight
- Type: 2-Hole
- Voltage Rating: 35
Panduit Pan-Lug Compression Lug Connector, 2-Hole, Series: LCC-W, Stranded Copper Conductor, 500 kcmil Conductor, Die Code: P87, 35 kV, 1/2 in Stud, Straight Tongue, 1.54 in W x 0.22 in THK Tongue, 6.12 in Overall Length, Long/Inspection Window Barrel, 0.84 in ID x 1.06 in OD x 2.5 in L Barrel, Specifications: 1-3/4 in Stud Hole Spacing, 2-9/16 in L Wire Strip, Tin Plated, 90 deg C, 2-9/16 in Mounting Hole, Tin Plated Copper, Brown
- Features
- The long barrel maximizes the number of crimps and provides premium wire pullout strength and performance
- Inspection window to visually assure full conductor insertion
- color-coded barrel marked with Panduit® and specified competitor die index numbers for proper crimp die selection
- Tin-plated to inhibit corrosion
- For use with stranded copper conductor
- Consult cable manufacturer for voltage stress relief instructions with application greater than 2000 V
- The generously beveled wire entry prevents bent back strands when inserting the conductor into the barrel
