Panduit LCCH300-12-X
Panduit Pan-Lug LCCH300-12-X LCCH 2-Hole Compression Lug, 300 kcmil Copper Conductor, Die Code: P66, 1/2 in Stud, Tin Plated Copper
Lug Compression Connectors
7614007
LCCH300-12-X
Panduit
$0.00
/ ea
- Barrel Size: 0.65 in ID x 0.81 in OD x 2.24 in L
- Barrel Type: Corona Relief Taper/Long without Inspection Window
- Color: White
- Conductor size: 300
- Conductor Type: Copper
- Die Code: P66
- Material: Tin Plated Copper
- Mounting Hole Size: 2-5/16
- Overall Length: 5.94
- Series: LCCH
- Specifications: 2.31 in L Wire Strip, 1-3/4 in Stud Hole Spacing
- Stud Size: 1/2
- Temperature Rating: 90
- Tongue Size: 1.19 in W x 0.16 in THK
- Tongue Type: Standard Straight
- Type: 2-Hole
- Voltage Rating: 35
Panduit Pan-Lug Compression Lug, 2-Hole, Series: LCCH, Copper Conductor, 300 kcmil Conductor, Die Code: P66, 35 kV, 1/2 in Stud, Standard Straight Tongue, 1.19 in W x 0.16 in THK Tongue, 5.94 in Overall Length, Corona Relief Taper/Long without Inspection Window Barrel, 0.65 in ID x 0.81 in OD x 2.24 in L Barrel, 2.31 in L Wire Strip, 1-3/4 in Stud Hole Spacing, 90 deg C, 2-5/16 in Mounting Hole, Tin Plated Copper, White
- Features
- Tin-plated to inhibit corrosion
- Color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
- Externally chamfered barrel end inhibits Corona effect when used in high voltage applications
- Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments
- To facilitate use with stranded copper conductors in applications of 5000 VAC or more
