Hubbell Wiring C460C7W
Wiring Device-Kellems C460C7W C Series 3-Phase Heavy Duty Insulated Standard Watertight Cord Mount Pin and Sleeve Connector, 480 VAC, 60 A, 3 Poles, 4 Wires, Red
Plugs Connectors
4487415
C460C7W
Hubbell Wiring
$0.00
/ ea
- Amperage Rating: 60
- Color: Red
- Dimensions: 4.43 in Dia x 10.61 in L
- Enclosure: IP67
- Grade: Industrial
- Material: Composite
- Number of Poles: 3
- Number Of Wires: 4
- Series: C Series
- Temperature Rating: -40 to 75
- terminal type: Pressure Screw
- Type: 3-Phase Heavy Duty Insulated Standard Watertight Cord Mount
- Voltage Rating: 480
Wiring Device-Kellems Pin and Sleeve Connector, 3-Phase Heavy Duty Insulated Standard Watertight Cord Mount, Series: C Series, 480 VAC, 60 A, 3 Pole, 4 Wires, Industrial Grade, IP67 Enclosure, -40 to 75 deg C, Pressure Screw Terminal, Composite, Red, 4.43 in Dia x 10.61 in L
- Features
- Nylon gland nut, cover arm, cord clamp assembly
- Polycarbonate cover
- Brass cover rivet, phase, ground sleeves
- Neoprene, EPDM, TPE, silicone gasket and seals
- Reinforced nylon retainer, contact carrier
- Plated steel terminal screw
