Woodhead 1549
Woodhead reg; Super-Safeway reg; 1549 130141 Male Plug, 250 VAC, 15 A, 2 Poles, 3 Wires, Yellow
Plugs Connectors
4294954
1549
Woodhead
$0.00
/ ea
- Amperage Rating: 15
- Color: Yellow
- Cord Diameter: 0.335 to 0.64
- Grade: Industrial
- Material: Rubber
- Nema Rating: NEMA 6-15
- Number of Poles: 2
- Number Of Wires: 3
- Series: 130141
- Temperature Rating: -40 to 75
- terminal type: Screw/Wire
- Voltage Rating: 250
Woodhead® Super-Safeway® Male Plug, Series: 130141, 250 VAC, 15 A, 2 Pole, 3 Wires, NEMA 6-15 Rating, Industrial Grade, 0.335 to 0.64 in Diameter Cord, -40 to 75 deg C, Screw/Wire Terminal, Rubber, Yellow
- Features
- NEoTEX® Paracril OZO rubber body yields the best performance for abrasion, chemical exposure and temperature extremes within the Super-Safeway™ offering
- Rugged nylon bodies within the Safeway® offering provide exceptional durability and performance
- Color coded 1/4 in terminal screws preset in open position, ready to wire
- Wire screw terminals are tri-drive to be used with straight blade, Phillips® and square drive screw drivers
- Floating blade construction provides self-alignment and a better mechanical and electrical connection minimizing wear and heat generation
- Transparent wiring guide to verify all wire strands are in place before securing wire
- Captive, tri-drive head, stainless steel, speed screw provides easy assembly and long life
- Two-piece cord clamp strain relief includes tri-drive screws to firmly secure the cord
- Nickel plated brass plug blades and connector contacts
- NEoTEX® Paracril OZO rubber Super-Safeway™ outer housing
- Nylon safeway outer housing
- Stainless steel face screw
- Nylon face insert
- Brass wire saddle clamp
- zinc plated steel cord clamp screws
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%
