Hubbell Wiring HBL5362OW
Hubbell HBL5362OW Duplex Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Office White
Receptacles
7078031
HBL5362OW
Hubbell Wiring
$0.00
/ ea
- Amperage Rating: 20
- Color: Office White
- Grade: Heavy Duty/Specification
- Horsepower: 1
- Material: Nylon
- Nema Rating: NEMA 5-20R
- Number of Poles: 2
- Number Of Wires: 3
- Temperature Rating: -40 to 75
- terminal type: Back/Side Wire
- Type: Duplex
- Voltage Rating: 125
Hubbell Straight Blade Receptacle, Duplex, 125 VAC, 20 A, 1 hp, 2 Pole, 3 Wires, NEMA 5-20R NEMA Rating, Heavy Duty/Specification Grade, -40 to 75 deg C, Back/Side Wire Terminal, Nylon, Office White
- Features
- Reinforced PET base
- 0.037 in brass power contact
- #10-32 silicon bronze (Ni plate if neutral) terminal and ground screw
- Finder groove face style
- Traditional face shape
- Nylon top material
- Stainless steel auto ground clip material, steel zinc-plated mounting screw material
- Withstands 2000 VAC minimum dielectric voltage
- Certified for current interrupting at full rated current interrupting
- 14 to 10 AWG copper stranded or solid conductor only terminal accommodation
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%
- 0.05 in brass mounting strap
- Ratings are a permanent part of the device product identification
