Signify VEZ2T42M3LD35M

Advance Mark 10 Powerline VEZ2T42M3LD35M Electronic Dimmable Compact Fluorescent Ballast, 4-Pin CFL Lamp, 42 W Lamp, 277 VAC, Programmed, 0.05 to 1 Ballast Factor
Ballasts, Starters and LED Drivers
5494683 VEZ2T42M3LD35M
Signify
$0.00 / ea

Signify VEZ2T42M3LD35M
  • Amperage Rating: 0.36
  • Ballast Factor: 0.05 to 1
  • Dimensions: 6.28 in L x 3 in W x 1.29 in H
  • Dimmable: Yes
  • Enclosure Type: NEMA 36
  • Frequency Rating: 60
  • Lamp Base Type: GX24Q 4-Pin
  • Lamp Type: 4-Pin CFL
  • Lamp Wattage: 42
  • Material: Metal
  • Number of Lamps: 2
  • Power Factor: 0.98
  • Start Type: Programmed
  • Temperature Range: 70
  • Total Harmonic Distortion: 10
  • Type: Electronic
  • Voltage Rating: 277
  • Wattage: 20 to 98
Signify Lighting, Ballast, Mark 10 POWERLINE, eFluo Dim, Min Start Temp 50C, Average Life 43800HRS, Volts 277V, Dimmable, Number of Lamps 2, Ballasts Factor 1PCT, Input Frequency 50/60HZ, Programmed Start Yes, , Certifications are UL, ISO, FCC
QTY
Add to Wishlist
  • Features
  • Triple CFL series lamp connection
  • 255 to 290 VAC applied voltage limits
  • Red color label identification
  • 20 to 24 dB average ambient noise level
  • High power factor
  • Length mounting feet with SmartMate® dual entry color coded connectors
  • Available in linear fluorescent and 4-pin compact fluorescent models
  • Full range continuous dimming (100% light output down to 5% - T5HO to 1%)
  • Compatible with controls from numerous manufacturers without using separate control leads - Powerline dimming interface
  • Ideal for frequent switching applications such as occupancy sensors and daylight harvesting - programmed start operation
