Lutron EC3DT442KU2S

EcoSystem EC3DT442KU2S Studded Compact Fluorescent Ballast, 42 W Lamp, 120/220/240/277 VAC, Programmed/Rapid
Connected Lighting and Controls
7221041 EC3DT442KU2S
Lutron
$0.00 / ea

Lutron EC3DT442KU2S
  • Amperage Rating: 0.73/0.39/0.35/0.31
  • Dimensions: 4.9 in L x 3 in W x 1 in H
  • Dimmable: Yes
  • Enclosure Type: NEMA 1
  • Lamp Wattage: 42
  • Minimum Starting Temperature: 10
  • Mounting Type: Tabs/Stud
  • Number of Lamps: 2
  • Power Factor: 0.95
  • Series: EC3DT
  • Start Type: Programmed/Rapid
  • Temperature Range: 75
  • Thermal Protection: Class P
  • Total Harmonic Distortion: <10
  • Type: Studded
  • Voltage Rating: 120/220/240/277
  • Wattage: 87.6/85.9/85.1/85.4
EcoSystem Compact Fluorescent Ballast, Studded, Series: EC3DT, 42 W Lamp, 87.6/85.9/85.1/85.4 W Wattage, 120/220/240/277 VAC, 0.73/0.39/0.35/0.31 A, Programmed/Rapid Start, 10 deg C Minimum Starting, Total Harmonic Distortion: <10 %, Power Factor: 0.95, Yes Dimmable, 2 Lamps, Thermal Protection: Class P, NEMA 1 Enclosure, 75 deg C, Tabs/Stud Mounting, 4.9 in L x 3 in W x 1 in H Dimensions
QTY
Add to Wishlist
  • Features
  • Continuous, flicker free dimming from 100% to 5%
  • Compatible with energy Savr Node™ with EcoSystem® devices, GRAFIK Eye® QS with EcoSystem® connection, PowPak™ dimming module with EcoSystem® connection and Quantum® systems, allowing for integration into an existing/planned EcoSystem® lighting control system
  • Supports standard 3-wire line voltage phase control technology
  • Programmed rapid start design ensures full rated lamp life while dimming and cycling
  • Lamps turn on to any dimmed level without flashing to full brightness
  • Low harmonic distortion throughout the entire dimming range
  • Frequency of operation ensures that ballast does not interfere with infrared devices
  • Inrush current limiting circuitry eliminates circuit breaker tripping, switch arcing and relay failure
  • Ultra-quiet operation
  • Protected from miswires of any input power to control lead or from lamp leads to each other and/or ground
  • End of lamp life protection circuitry ensures safe operation throughout entire lamp life
  • Non-volatile memory restores all ballast settings after power failure
  • 100% compatible with all Lutron® 3-wire fluorescent controls and EcoSystem® digital controls
  • 100% performance tested at factory
  • For T4 4-pin triple tube
