Lutron EC3DT4MWKU1
EcoSystem EC3DT4MWKU1 Non-Studded Compact Fluorescent Ballast, 26 W Lamp, 120/220/240/277 VAC, Programmed/Rapid
Connected Lighting and Controls
7224024
EC3DT4MWKU1
Lutron
$0.00
/ ea
- Amperage Rating: 0.22/0.12/0.11/0.1
- Dimensions: 4.9 in L x 3 in W x 1 in H
- Minimum Starting Temperature: 10
- Mounting Type: Tabs/Stud
- Number of Lamps: 1
- Power Factor: 0.95
- Series: EC3DT
- Start Type: Programmed/Rapid
- Dimmable: Yes
- Enclosure Type: NEMA 1
- Lamp Wattage: 26
- Temperature Range: 75
- Thermal Protection: Class P
- Total Harmonic Distortion: <10
- Type: Non-Studded
- Voltage Rating: 120/220/240/277
- Wattage: 26.4/26.8/26.9/27
EcoSystem 5 percent 3-Wire and EcoSystem Digital Link Controlled T4 Compact, 1 lamp, ballast factor of 0.95, K-can, 26/32W
- Features
- Continuous, flicker free dimming from 100% to 5%
- Compatible with energy Savr Node™ with EcoSystem® devices, GRAFIK Eye® QS with EcoSystem® connection, PowPak™ dimming module with EcoSystem® connection and Quantum® systems, allowing for integration into an existing/planned EcoSystem® lighting control system
- Supports standard 3-wire line voltage phase control technology
- Programmed rapid start design ensures full rated lamp life while dimming and cycling
- Lamps turn on to any dimmed level without flashing to full brightness
- Low harmonic distortion throughout the entire dimming range
- Frequency of operation ensures that ballast does not interfere with infrared devices
- Inrush current limiting circuitry eliminates circuit breaker tripping, switch arcing and relay failure
- Ultra-quiet operation
- Protected from miswires of any input power to control lead or from lamp leads to each other and/or ground
- End of lamp life protection circuitry ensures safe operation throughout entire lamp life
- Non-volatile memory restores all ballast settings after power failure
- 100% compatible with all Lutron® 3-wire fluorescent controls and EcoSystem® digital controls
- 100% performance tested at factory
- For T4 4-pin quad tube/triple tube
