Toshiba 0154SDJR41P-P

Toshiba EQP Global 0154SDJR41P-P Close-Coupled Continuous-Duty Type IKH Definite Purpose AC Motor, Totally Enclosed Fan Cooled Enclosure, 15 hp, 230/460 VAC, 60 Hz, 3 ph Phase, 254JP Frame, 1800 rpm Speed, Footed Mount
AC Motors
7565610 0154SDJR41P-P
Toshiba
$0.00 / ea

Toshiba 0154SDJR41P-P
  • Amperage Rating: 38/19
  • Application Type: Oil Well Pumping Motors
  • Bearing Type: Ball
  • Constant Torque Speed Range: 10:1
  • Dimensions: 29.8 in L x 14.9 in H
  • Enclosure Type: Totally Enclosed Fan Cooled
  • Frame: 254JP
  • Frequency Rating: 60
  • Horsepower: 15
  • Insulation Class: Class F
  • Material: Cast Iron
  • Mounting Type: Footed
  • Phase: 3
  • Rotation: CW/CCW
  • Service Factor: 1.15
  • Shaft Size: 1.249
  • Speed: 1800
  • Temperature Rating: 40
  • Torque Rating: 44.5
  • Type: Close-Coupled Continuous-Duty Type IKH
  • Variable Torque Speed Range: 60:1
  • Voltage Rating: 230/460
Toshiba EQP Global Definite Purpose AC Motor, Close-Coupled Continuous-Duty Type IKH, Oil Well Pumping Motors Application, 15 hp, 230/460 VAC, 38/19 A, 60 Hz Frequency, 3 ph ph, 1800 rpm Speed, Totally Enclosed Fan Cooled Enclosure, 254JP Frame, 1.249 in Shaft, CW/CCW Rotation, 1.15 Service Factor, Ball Bearing, 44.5 ft-lb Torque, Footed Mounting, 40 deg C, Insulation Class: Class F, Cast Iron, 10:1 Constant Torque Speed, 60:1 Variable Torque Speed, 29.8 in L x 14.9 in H Dimensions
QTY
Add to Wishlist
  • Features
  • IP55 protection
  • Cast iron frame, brackets and conduit box
  • Oversized 300 series bearing on all frames
  • Regreasable 280 frame and larger
