Toshiba Y754XPEA42A-P

Toshiba EQP Global Y754XPEA42A-P XP Series Continuous-Duty Type IKH AC Motor, Totally Enclosed Fan Cooled Enclosure, 7.5 hp, 230/460 VAC, 60 Hz, 3 ph Phase, 213TC Frame, 1800 rpm Speed, C-Face Footed Mount
AC Motors
7574009 Y754XPEA42A-P
Toshiba
$0.00 / ea

Toshiba Y754XPEA42A-P
  • Amperage Rating: 19.6/9.8
  • Application Type: General Purpose AC Motors, Compressor Motors, Fan & Blower Motors
  • Bearing Type: Ball
  • Constant Torque Speed Range: 20:1
  • Dimensions: 19.6 in L x 13.35 in H
  • Enclosure Type: Totally Enclosed Fan Cooled
  • Frame: 213TC
  • Frequency Rating: 60
  • Horsepower: 7.5
  • Insulation Class: Class F
  • Material: Cast Iron
  • Mounting Type: C-Face Footed
  • Phase: 3
  • Rotation: CW/CCW
  • Series: XP Series
  • Service Factor: 1.15
  • Shaft Size: 1-3/8
  • Special Features: Explosion Proof AC Motors
  • Speed: 1800
  • Temperature Rating: 40
  • Torque Rating: 22.4
  • Type: Continuous-Duty Type IKH
  • Variable Torque Speed Range: 60:1
  • Voltage Rating: 230/460
Toshiba EQP Global AC Motor, Continuous-Duty Type IKH, Series: XP Series, General Purpose AC Motors, Compressor Motors, Fan & Blower Motors Application, Explosion Proof AC Motors Special Features, 7.5 hp, 230/460 VAC, 19.6/9.8 A, 60 Hz Frequency, 3 ph ph, 1800 rpm Speed, Totally Enclosed Fan Cooled Enclosure, 213TC Frame, 1-3/8 in Shaft, CW/CCW Rotation, 1.15 Service Factor, Ball Bearing, 22.4 ft-lb Torque, C-Face Footed Mounting, 40 deg C, Insulation Class: Class F, Cast Iron, 20:1 Constant Torque Speed, 60:1 Variable Torque Speed, 19.6 in L x 13.35 in H Dimensions
QTY
Add to Wishlist
  • Features
  • NEMA design B
  • Cast iron frame and brackets
  • Non-sparking brass shaft slingers
  • IP56 protection
  • Normally-closed thermostats
