Legrand PS81120I
Pass & Seymour PS81120I Back/Side Wired Specification Grade Combination Switch/Receptacle, 20 A, 277 VAC, 1 Poles
Decorator and Rocker Switch
6969298
PS81120I
Legrand
$0.00
/ ea
- Actuator: Rocking Paddle Up/Down
- Color: Ivory
- Electrical Ratings: 20 A, 277 VAC
- Enclosure: NEMA WD-1/WD-6
- Environmental Conditions: -40 to 115 deg C Operating Temperature
- Material: Polycarbonate
- Mounting: Wall
- Number of Poles: 1
- Operating Cycles: 50000
- Size: 1.29 in L x 1.59 in W x 3.812 in H
- Type: Back/Side Wired Specification Grade
Decorator Combo Switch Ivory
- Features
- Impact-resistant polycarbonate back body and frame
- Unique single rocking butterfly contact provides long-term consistent performance with significantly fewer moving parts
- Side and external screw pressure plate back wire accepts 12 and 14 AWG
- Internal screw pressure plate back and side wire capability for easy installation with 14 to 10 AWG stranded or solid copper clad wire
- Terminals made of high conductivity brass and serrated for maximum wire gripping
- Silver alloy contacts integrally formed to the butterfly actuator assures reliable performance
- Integral auto-ground clip for positive ground to metal boxes
- Tri-drive ground, terminal and mounting screws
- All terminal screws backed out, ready-to-install
- Full wraparound heavy gauge steel strap is plated for corrosion resistance and features lock in tabs
- Unique up down switches match the look and feel of standard decorator switches
- Patent pending split circuit tab easily accessible and can be reinstalled without a tool
- Patent pending snap-in light module (sold separately) transforms a combination switch into an illuminated switch
- Maximum 30 deg C at rated current temperature rise
- Cushioned thermoplastic paddle assures smooth, quiet, long-term operation
- All screws are tri-drive
