Legrand PS520P9W
Pass & Seymour PS520P9-W 3-Phase Watertight Pin and Sleeve Plug, 120/208 VAC, 20 A, 4 Poles, 5 Wires, Black
Pin and Sleeve Devices
7238416
PS520P9W
Legrand
$0.00
/ ea
- Amperage Rating: 20
- Color: Black
- Dimensions: 7-1/4
- Enclosure: IP67
- Frequency Rating: 60 to 400
- Grade: Commercial
- Material: Thermoplastic
- Number of Poles: 4
- Number Of Wires: 5
- Temperature Rating: -50 to 80
- terminal type: Screw
- Type: 3-Phase Watertight
- Voltage Rating: 120/208
Four pole, Five wire, Pin and Sleeve Plug. 20 amp 120/208 volt.
- Features
- All P and S watertight pin and sleeve plugs, connectors, receptacles and inlets bring you the features to enhance versatility, reliability and safety
- North American products come completely ready to wire, for quick, simple installation
- All feature chemical-resistant thermoplastic construction
- Shrouded, nickel plated, solid brass pins provide corrosion protection and excellent conductivity
- An exclusive, hinged cord-grip eliminates loose parts that get lost
- IEC 309-2 clock position 9 configuration
