Legrand PS5466HGAN

Pass & Seymour PS5466-HGAN Extra Hard Use Straight Blade Plug, 250 VAC, 20 A, 2 Poles, 3 Wires, Black/White
Plugs Connectors
6799440 PS5466HGAN
Legrand
$0.00 / ea

Legrand PS5466HGAN
  • Amperage Rating: 20
  • Color: Black/White
  • Cord Diameter: 0.32 to 0.655
  • Dimensions: 2.13 in H x 1.53 in W x 1.35 in D
  • Enclosure: IP20
  • Grade: Commercial/Hospital
  • Material: Nylon
  • Nema Rating: NEMA 6-20P
  • Number of Poles: 2
  • Number Of Wires: 3
  • Temperature Rating: -40 to 75
  • Type: Extra Hard Use
  • Voltage Rating: 250
Straight Blade Angle Plug 3way, 20Amp 250Volt Hospital Grade
QTY
Add to Wishlist
  • Features
  • Angle plugs and adapters both allow for 4-position face rotation
  • Tri-drive assembly and cord-grip screws standard on all angle adapters
  • Angle adapter will accommodate all Pass & Seymour® EHU style straight blade plugs and connectors on a retrofit basis
  • Simply remove the straight handle body from the plug or connector face assembly and replace with the angle adapter
  • 18 to 10 AWG wire size
  • Self-centering cord grip, transparent terminal cover, rugged nylon housing
