Legrand PT1597W
Pass & Seymour PlugTail PT1597W Duplex Self-Test GFCI Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, White
Receptacles
7734175
PT1597W
Legrand
$0.00
/ ea
- Amperage Rating: 15
- Color: White
- Dimensions: 1.03 in L x 1.73 in W x 4.2 in H
- Frequency Rating: 60
- Grade: Specification
- Material: Thermoplastic
- Nema Rating: NEMA 5-15R
- Number of Poles: 2
- Number Of Wires: 3
- Temperature Rating: -35 to 66
- terminal type: PlugTail
- Type: Duplex Self-Test
- Voltage Rating: 125
Pass & Seymour PlugTail GFCI Receptacle, Duplex Self-Test, 125 VAC, 15 A, 60 Hz Frequency, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Specification Grade, -35 to 66 deg C, PlugTail Terminal, Thermoplastic, White, 1.03 in L x 1.73 in W x 4.2 in H Dimensions
- Features
- Faster, more reliable installation
- Auto-ground clip assures a positive ground to metal box
- Thinner than competitor's GFCI receptacle, leaves more room for wires in the box
- Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections to PlugTail® connector
- GFCI works with existing 3-wire PlugTail® connectors creating a non feed-through application for facility owners
- 10 kA short circuit rating
- Mounting screws are shipped captive in the device and wallplate for easier installation
- Button colors match the device face
- Trip-indicator light (red LED)
- Dual direction test and reset buttons
- Zinc-plated steel mounting strap
- High Impact-resistant thermoplastic construction
- Exceeds UL 943 voltage surge requirements, survives 100x the required UL 3 kA/6 kV voltage surge test cycles
- 5 +/- 1 m trip threshold
- Tri-drive screws
