Legrand TR8201I

Pass & Seymour TR8201I Single Tamper-Resistant Straight Blade Receptacle, 125 VAC, 15 A, Ivory
Receptacles
7563284 TR8201I
Legrand
$0.00 / ea

Legrand TR8201I
  • Amperage Rating: 15
  • Color: Ivory
  • Dimensions: 1.093 in L x 1.32 in W x 3.28 in H
  • Grade: Hospital
  • Material: Nylon/PVC
  • Nema Rating: NEMA 5-15R
  • Temperature Rating: -40 to 60
  • terminal type: Back/Side Wire
  • Type: Single Tamper-Resistant
  • Voltage Rating: 125
Pass & Seymour Straight Blade Receptacle, Single Tamper-Resistant, 125 VAC, 15 A, NEMA 5-15R NEMA Rating, Hospital Grade, -40 to 60 deg C, Back/Side Wire Terminal, Nylon/PVC, Ivory, 1.093 in L x 1.32 in W x 3.28 in H Dimensions
QTY
Add to Wishlist
  • Features
  • 0.032 in thick, brass, triple wipe power contacts for lasting retention
  • Tri drive steel terminal screws, internal screw pressure plate back and side wire capability 2-back wire holes for more wiring flexibility
  • Dual mechanical shutter system to help prevent insertion of foreign objects
  • Heavy duty zinc plated steel strap for added strength
  • Strap tabs wrap around face to prevent strap from separating from face and back body
  • 2-drive screws anchor strap to back body and face where abrupt removal torque is strongest
  • Auto ground eliminates the necessity to terminate grounding conductor to device
