nVent Hoffman G1500900425G
nVent HOFFMAN FUSION G7™ G1500900425G A4G Enclosure, 1500 mm L x 900 mm W x 425 mm D, NEMA 4/12/13/IP66 NEMA Rating, Steel
Wall Mount Enclosures
7078217
G1500900425G
nVent Hoffman
$0.00
/ ea
nVent HOFFMAN FUSION G7 Enclosure, Series: A4G, 1500 mm Length, 900 mm Width, 425 mm Depth, NEMA 4/12/13/IP66, Wall Mount, Steel, Polyester Powder Painted, Light Gray
- Features
- Seamless foam in place gasket
- Reversible door with sealed hinges and hinge brackets
- Gland plates for enclosure bottom
- Bonding provision on door, grounding stud on body
- External formed 90 deg body flange
- Three-point latching on enclosures 1000 mm high and taller
- Door alignment device on doors with three-point latching and 800 mm or wider
- Pre-cut gland plate opening in enclosure bottom
- quarter-turn latches with 3 mm double bit insert
- Corner formed door
- Simple easy-to-remove and install hinge pins with captivation clip
- High torque threadless studs and fasteners on door
- Wide assortment of user friendly internal accessories to increase internal mounting area capability and design flexibility
- Hinged on right side
